Mobile PU Twin 70
2 x 35m3/h @ 3bar
The Mobil PU Twin 70 is a dual pump unit with a total capacity of 70 m³/h. It is designed to provide reliable fluid transport and circulation in industrial systems. Ideal for use in factories, plants, and temporary installations.
Twin pumps
Parallel operation
92 m3/h @ 2 Bar
400v/3ph/50hz/32A
80 kg
Plug’n Play
Connection with flexible hoses
Technical specifications
| Description | Unit | Value |
|---|---|---|
| Max flow | m3/h | 92 |
| Max lifting height | m | 42 |
| Work pressure | bar | 0.5 to 10 |
| Electrical connection | type | CEE 32A 400V / 3ph / 50Hz |
| Effect | kW | 11 |
| Power draw | A | 21 |
| Connection | inch | 4 |
| Weight | kg | 100 |
| Dimensions L x W x H | mm | 1200 x 800 x 1000 |
